| Wireless Standard |
- 802.11 b/g/n 2.4 GHz
- 802.11 a/n/ac 5 GHz
|
| Wireless Transfer Rate |
- Transmit:
- 800 Mbps* for 2.4 GHz
- 1733 Mbps* for 5 GHz
- Receive:
- 800 Mbps* for 2.4 GHz
- 1733 Mbps* for 5 GHz
|
| Wireless Security |
- WPA2-PSK, WPA-PSK, WPA-Enterprise, WPA2-Enterprise
- WPS support
|
| WLAN Features |
- MU-MIMO
- Guest Wi-Fi
- Wi-Fi Protected Setup (WPS)
- Wi-Fi Multimedia (WMM)
- Auto channel selection
- Wireless scheduling
- Wireless output power management
- MAC address filtering
|
| Routing |
- WAN type: Static IP, DHCP, PPPoE, PPTP
- IGMP v1/v2
- Auto-IP change
- IPv4/IPv6
- Network Address Translation (NAT)
- Port trigger
- DHCP server/client
- DNS relay
- Dynamic DNS
|
| NAT ALG and Pass-through |
- PPTP
- L2TP
- IPSec
- FTP
- SIP
- H.323
- RTSP
- IRC
- SNMP
|
| Firewall |
- Stateful Packet Inspection (SPI)
- Deny of Service (DoS) Prevention
- MAC filter
- TCP/IP filter
|
| Application Control |
- Usage monitor
- Zyxel Photo App
- Smart QoS (StreamBoost)
- Parental control
- ONE Connect
|
| USB Support |
- Mass storage support by SMB/CIFS/FTP/WebDAV
- Print server
|
| Media Server |
DLNA |
| System Management |
- Online firmware upgrade
- Remote management
- Wake on LAN
- UPnP
|
| Operation Mode |
- Router mode
- Access point mode
|
| CPU |
1.7 GHz dual core processor |
| Memory |
512 MB RAM and 4 GB eMMC |
| WAN |
One 10/100/1000 Mbps Ethernet RJ-45 port with auto MDI/MDIX support |
| LAN |
Four 10/100/1000 Mbps Ethernet RJ-45 ports with auto MDI/MDIX support |
| Antenna |
Four dual-band high performance antennas |
| USB |
|
| LED indicator |
- Power/SYS
- Internet
- Wireless 2.4G/WPS
- Wireless 5G/WPS
|
| Buttons |
- Power switch
- Reset butto
- WPS button
- Wireless on/off button
|
| Power |
12 VDC, 3 A |
| Power consumption |
25 W |
| Item dimensions (WxDxH)(mm/in.) |
250 x 168 x 51 / 9.8 x 6.6 x 2 |
| Item weight (kg/lb) |
0.57 / 1.26 |
| Packing dimensions (WxDxH)(mm/in.) |
445 x 258 x 60 / 17.5 x 10.2 x 2.4 |
| Packing weight (kg/lb) |
1.56 / 3.44 |
| Package Contents |
- Wireless router x1
- Power adapter x1
- Ethernet cable x1
- Quick start guide (Warranty card included) x1
|
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Operating Humidity |
10% to 90% (Non-condensing) |
| Storage Temperature |
-30°C to 70°C (-22°F to 158°F) |
| Storage Humidity |
10% to 95% (Non-condensing) |
| Safety |
CE-LVD, BSMI |
| EMC |
CE, FCC, IC, BSMI |
