Zebra Zebra ZD22042-D0EG00EZ
| Printer Specifications | |
|---|---|
| Physical Dimensions | Thermal Transfer: 10.5 in. x 7.75 in. x 7.5 in. (267 mm x 197 mm x 191 mm) Direct Thermal: 8.6 in. x 6.9 in. x 5.9 in. (220 mm x 176 mm x 151 mm) |
| Weight | Thermal Transfer: 3.7 lbs / 1.7 kg Direct Thermal: 2.5 lbs / 1.1 kg |
| Resolution | 203 dpi / 8 dots per mm |
| Memory | 128 MB Flash; 128 MB SDRAM |
| Max Print Width | 4.09 in. / 104 mm |
| Print Speed | 4 in./102 mm per second |
| Media Sensors | Movable black mark sensor (limited range), fixed off-center gap sensor |
| Firmware | ZPL II, EPL 2, XML |
| Media Characteristics | Max Label Length: 39.0 in. / 991 mm Media Width: 1.00–4.4 in. / 25.4–112 mm Roll Size: 5.00 in. / 127 mm OD Core: 0.5 in., 1.0 in. std; 1.5 in. optional Thickness: 0.003–0.0075 in. (tear-off mode only) Types: Roll-fed, fan-fold, die cut, continuous, tag stock, receipt paper, wristbands |
| Ribbon Characteristics | OD: 1.34 in. / 34 mm (74 m) Max Length: 244 ft. / 74 m Ratio: 1:1 ribbon to media Width: 1.33–4.3 in. / 33.8–109.2 mm Core I.D.: 0.5 in. / 12.7 mm |
| Operating Temp. | 40°–105°F / 4.4°–41°C |
| Storage Temp. | -40°–140°F / -40°–60°C |
| Humidity | Operating: 10%–90% non-condensing Storage: 5%–95% non-condensing |
| Electrical | Auto-detect 100–240VAC, 50–60Hz; ENERGY STAR® qualified |
| Media Handling | Factory-installed peeler |
| Real Time Clock | None |
| Bar Code Support | 1D: Code 11, 39, 93, 128, ISBT-128, UPC-A/E, EAN-8/13, etc. 2D: PDF417, QR Code, DataMatrix, MaxiCode, Aztec, etc. |
| Fonts and Graphics | 16 ZPL II bitmap fonts, 2 scalable ZPL fonts, 5 EPL2 fonts OpenType font support Unicode compliant 50 MB user Flash, 8 MB user SDRAM |
| Regulatory | IEC 60950-1, EN55022 Class B, FCC Class B, CE, VCCI, CCC, BIS, NOM, etc. |
| Recommended Services | Zebra OneCare™ Essential: includes printhead coverage, 8×5 support, 3-day repair turnaround, online RMA |
| Operating System | Link-OS® Basic |
| Print DNA Software | Zebra Setup Utilities, ZebraDesigner Essentials, Emulations |
