Tp-Link TpLink WA3001
Interface 1 Gigabit Port (Supports Passive PoE)
Button Power On/Off Button, WPS Button, Reset Button
External Power Supply 48V/0.5A
Dimensions ( W x D x H ) 9.4×6.5×1.7 in (240x165x43.6mm)
Antenna Type 4 Fixed High Performance Antennas
WIRELESS FEATURES
Wireless Standards IEEE802.11b/g/n/ax 2.4 GHz, IEEE 802.11a/n/ac/ax 5 GHz
Frequency 2.4 GHz and 5 GHz
Signal Rate 2402 Mbps at 5 GHz, 574 Mbps at 2.4 GHz
Reception Sensitivity 5 GHz:
11ax HE20 MCS0:-97dBm, 11ac VHT20 MCS9:-73dBm, 11ax HE20 MCS11:-67dBm
11ax HE40 MCS0:-94dBm, 11ac VHT40 MCS9:-70dBm, 11ax HE40 MCS11:-63dBm
11ax HE80 MCS0:-91dBm, 11ac VHT80 MCS9:-66dBm, 11ax HE80 MCS11:-60dBm
11ac VHT160 MCS9:-63dBm, 11ax HE160 MCS11:-58dBm
2.4 GHz:
11ac VHT20 MCS0:-97dBm, 11ac VHT20 MCS8:-73dBm, 11ax HE20 MCS11:-65dBm
11ac VHT40 MCS0:-93dBm, 11ac VHT40 MCS9:-69dBm, 11ax HE40 MCS11:-62dBm
Transmit Power FCC: <23dBm(2.4GHz), <22dBm(5GHz)
Wireless Functions Enable/Disable Wireless Radio, WMM, Wireless Statistics, Access Control
Wireless Security WPA, WPA2, WPA3, WPA/WPA2-Enterprise encryptions
SOFTWARE FEATURES
Quality of Service WMM
Operating Modes Access Point, Range Extender, Client, Multi-SSID
System Tools SNMP, Ping Watchdog
DHCP Server, DHCP Client List
Protocols IPv4, IPv6
OTHERS
Certification FCC, RoHS
Package Contents Wireless Access Point TL-WA3001
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
PoE Power Injector
