| HARDWARE FUNCTIONS | |
|---|---|
| Processor | 1.8GHz quad-core CPU and three co-processors |
| Standards and protocols | 802.11a/b/g/n/ac, 802.3ab |
| Ports | 1x WAN 8x GE LAN 2x USB3.0 |
| Button | 1x Power 1x Wi-Fi On/Off 1x WPS 1x Reset 1x LED On/Off |
| LED Panel | 1x LED with multiple state |
| Mass | 3.3lb(with antennas) 2.65lb(without antennas)1.5kg(with antennas) 1.2kg(without antennas) |
| Dimensions( L x D x H ) | 11.3 X 11.3X 7.2 in.(with antennas) 9.5X9.5X2.2 in.(without antennas)288X288X184mm(with antennas) 240.6X240.6X55.4mm(without antennas) |
| Antenne | 8 external and detachable antennas <30dBm |
| Chipset | MU-MIMO Beamforming Airtime Fairness RangeBoost NitroQAM |
| WIRELESS FUNCTIONS | |
|---|---|
| Frequency | 1000Mbps @ 2.4GHz 2167Mbps @ 5GHz 2167Mbps @ 5GHz |
| SOFTWARE FUNCTIONS | |
|---|---|
| Management | Tether App Andriod 4.1 or higher iOS 8 or higher |
| System Tools | Time Settings Diagnostics Fw OTA Upgrade Config backup/resotre Administration Syslog SNMP Statistics LED Control |
| Basic Functionality | Network Map(Internet Status/Client List/Speedtest) Internet Settings Wireless Settings USB Sharing Settings(USB Storage Sharing/FTP Server/Print Server/Media Server) HomeCare(Parental Control/Antivirus/QoS) Guest Network Settings TP-Link Cloud Settings Multiple Languages |
| Protocol | IPv4, IPv6 |
| Advanced Functions | Working Mode (Router Mode or AP Mode) Wireless Schedule Time Machine TP-Link DDNS Parental Controls/Antivirus/QoS IPv6 VPN Server (OpenVPN and PPTP Servers) NAT Forwarding(DMZ/UPnP?) Link aggregation(WAN/LAN) Airtime Fairness SmartConnect Portal Authentication for Guest Wi-Fi |
| Supported Operating Systems | Time Settings Diagnostics Fw OTA Upgrade Config backup/resotre Administration Syslog SNMP Statistics LED Control |
General
Brand
- TP-LINK
Model
- AC5400x
Date first available
- 19 August, 2018
Shipping Weight
- 1.30 Kg
Shipping Dimensions
- 23.00 cm x 23.00 cm x 4.30 cm
