QNAP QNAP TS-216G-US
CPU ARM 4-core Cortex-A55 2.0GHz processor
CPU Architecture 64-bit ARM
Graphic Processors Mali-G52
Floating Point Unit Yes
Encryption Engine Yes
Hardware-accelerated Transcoding Yes
Neural Processing Unit (NPU) Yes
System Memory 4 GB on board (non-expandable)
Note: Reserves some RAM for use as shared graphics memory.
Maximum Memory 4 GB on board (non-expandable)
Flash Memory 4 GB (Dual boot OS protection)
Drive Bay 2x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility 3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable Yes
Gigabit Ethernet Port (RJ45) 1
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 1 (2.5G/1G/100M)
Wake on LAN (WOL) Yes
Jumbo Frame Yes
USB 2.0 port 2
USB 3.2 Gen 1 port 1
Form Factor Tower
LED Indicators System Status, LAN, USB, HDD1~2
Buttons Power, Reset, USB Copy
Dimensions (HxWxD) 6.5 x 4.02 x 8.69 inch
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
Weight (Net) 3.2 lbs
Weight (Gross) 5.31 lbs
Operating Temperature 0 – 40 C (32F – 104F)
Storage Temperature -20 – 70C (-4F – 158F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27C (80.6F)
Power Supply Unit Minimum 48W adapter (12VDC), 100-240VAC
Power Consumption: Disk Standby Mode 4.973
Power Consumption: Operating Mode, Typical 13.907 W
Tested with drives fully populated.
Fan 1 x 70mm, 12VDC
System Warning Buzzer
Kensington Security Slot Yes
Max. Number of Concurrent Connections 200
(CIFS) – with Max. Memory
