Mercusys Mercusys MB235-4G
Buy Mercusys MB235-4G 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router
| MB235-4G – 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router Specifications | |
|---|---|
| Wireless | |
| Network Type (EU) | FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz) TDD-LTE: B38/B40 (2600/2300 MHz) HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz) |
| Wi-Fi Class | AC1200 |
| Wi-Fi Speeds | 2.4 GHz: 300 Mbps, 5 GHz: 867 Mbps |
| Wireless Standards | IEEE 802.11ac/a/b/g/n |
| Frequency | 2.4 GHz, 5 GHz |
| Reception Sensitivity | 2.4 GHz: 11g 6Mbps: -95 dBm, 54Mbps: -77 dBm 11n HT20 MCS7: -74 dBm, HT40 MCS7: -71 dBm 5 GHz: 11a 6Mbps: -92 dBm, 54Mbps: -75 dBm 11ac VHT20 MCS8: -70 dBm VHT40 MCS9: -65 dBm VHT80 MCS9: -61 dBm |
| Transmission Power | 2.4 GHz: < 20 dBm, 5 GHz: < 23 dBm (EIRP) |
| Wireless Security | WPA-PSK / WPA2-PSK / WPA3-SAE |
| Wireless Functions | Smart Connect, WPS, Wireless Schedule |
| Hardware | |
| Dimensions | 209 × 171.9 × 41.7 mm (8.2 × 6.8 × 1.6 in) |
| Interfaces | 1× Gigabit LAN/WAN Port 3× Gigabit LAN Ports 1× Nano SIM Card Slot |
| Antennas | 2× External Detachable 4G LTE Antennas 2× External Wi-Fi Antennas |
| Buttons | WPS, Reset |
| Power Supply | 12V / 1A |
| LED Indicators | Power, Internet, LAN, 3× Signal |
| Cellular Network | |
| LTE Standard | Cat 6 – 300 Mbps DL / 50 Mbps UL |
| Operation Modes | 3G/4G Router, Wireless Router |
| Cellular Modes | 4G Mode, 3G Mode |
| Cellular APN Features | Data Roaming, Band Search, Network Search, Profile Create, APN Settings, ISP File Upgrade, PIN Management |
| Software Features | |
| WAN Modes | Dynamic IP, Static IP, PPPoE, PPTP, L2TP |
| NAT Forwarding | ALG, Virtual Server, Port Triggering, UPnP, DMZ |
| Protocols | IPv4, IPv6 |
| Data Settings | Data Statistics, Data Limit |
| Parental Controls | Time Control, Website Filtering |
| Guest Network | 2.4 GHz & 5 GHz |
| DHCP | Server, Client List, Address Reservation |
| DDNS | MERCUSYS DDNS, DynDNS, NO-IP |
| SMS Functions | Inbox, Outbox, Drafts, New Message |
| QoS | Supported |
| Security | IPv4 SPI Firewall, Access Control, IP & MAC Binding, IPv6 Firewall |
| System Settings | Time & Language, LED Control, Diagnostics, Firmware Upgrade, Backup & Restore, Reboot, Administration, System Log, CWMP (TR-069) Settings |
| Device Management | MERCUSYS App, Web GUI |
| Languages | English, Deutsch, Español, Français, Italiano, Polski, Русский |
| TR-069 | Supported |
| Package Contents | |
| Included Items | • MB235-4G AC1200 Router • Power Adapter • RJ45 Ethernet Cable • Quick Installation Guide |
| Environment | |
| Operating Temperature | 0°C~40°C (32°F~104°F) |
| Storage Temperature | -40°C~60°C (-40°F~140°F) |
| Operating Humidity | 10%~90% Non-Condensing |
| Storage Humidity | 5%~90% Non-Condensing |
