Mercusys Mercusys MB135-4G
Buy Mercusys MB135-4G AC1200 Wireless Dual Band 4G LTE Router
| MB135-4G – AC1200 Wireless Dual Band 4G LTE Router Specifications | |
|---|---|
| Wireless | |
| Network Type (EU) | FDD-LTE: B1/B3/B5/B7/B8/B20/B28 TDD-LTE: B38/B40 UMTS: B1/B5/B8 |
| Wi-Fi Class | AC1200 |
| Wi-Fi Speeds | 300 Mbps (2.4 GHz) + 867 Mbps (5 GHz) |
| Wireless Standards | IEEE 802.11ac/a/b/g/n |
| Frequencies | 2.4 GHz, 5 GHz |
| Reception Sensitivity | 2.4 GHz: 11g 6Mbps: -95dBm, 54Mbps: -77dBm 11n HT20 MCS7: -74dBm, HT40 MCS7: -71dBm 5 GHz: 11a 6Mbps: -92dBm, 54Mbps: -75dBm 11ac VHT20 MCS8: -70dBm 11ac VHT40 MCS9: -65dBm 11ac VHT80 MCS9: -61dBm |
| Transmission Power | 2.4 GHz < 20dBm, 5 GHz < 23dBm (EIRP) |
| Wireless Security | WPA-PSK / WPA2-PSK |
| Wireless Functions | Smart Connect, WPS, Wireless Schedule, Wireless Client Statistics |
| Hardware | |
| Dimensions | 219 × 140 × 32 mm (8.62 × 5.51 × 1.26 in) |
| Interfaces | 1× 10/100 Mbps LAN/WAN Port 3× 10/100 Mbps LAN Ports 1× Nano SIM Card Slot |
| Antennas | 2× External 4G LTE Antennas (Detachable), 2× External Wi-Fi Antennas |
| Buttons | WPS/Wi-Fi, Reset |
| LED Indicators | Power, Internet, LAN, 3× Signal |
| External Power Supply | 12V/1A |
| LTE Standard | Cat 4 (150 Mbps DL / 50 Mbps UL) |
| Software | |
| Operation Modes | 3G/4G Router, Wireless Router |
| Cellular Modes | 4G Preferred, 4G Only, 3G Only |
| Cellular APN | Data Roaming, Network Search, Profile Create, APN Settings, ISP File Upgrade, PIN Management |
| WAN Types | Dynamic IP, Static IP, PPPoE, PPTP, L2TP |
| NAT Forwarding | ALG, Virtual Server, Port Triggering, UPnP, DMZ |
| Protocols | IPv4, IPv6 |
| Data Settings | Data Statistics, Data Limit |
| Parental Controls | Time Control, Website Filtering |
| Guest Network | 2.4 GHz, 5 GHz |
| DHCP | Server, Client List, Address Reservation |
| DDNS | MERCUSYS DDNS, DynDNS, NO-IP |
| VPN Server | OpenVPN, PPTP, VPN Connections |
| SMS | Inbox, New Message, Outbox, Drafts |
| QoS | Supported |
| Security | SPI Firewall, DoS Protection, Service Filtering, Access Control, IP & MAC Binding, IPv6 Firewall |
| System Settings | Time Settings, LED Control, Diagnostics, Firmware Upgrade, Backup & Restore, Reboot, Admin, System Log, CWMP, SNMP, Traffic Monitor |
| Device Management | MERCUSYS App, Web GUI |
| System Languages | English, German, Spanish, Greek, French, Italian, Polish, Indonesian, Russian, Thai |
| TR-069 Support | Yes |
| Others | |
| Package Contents | MB135-4G Router Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
| Operating Environment | Temp: 0°C~40°C (32°F~104°F) Humidity: 10%~90% (Non-Condensing) |
| Storage Environment | Temp: -40°C~60°C (-40°F~140°F) Humidity: 5%~90% (Non-Condensing) |
