TECHNICAL SPECS
- Wi-Fi Technology:
AC5400 MU-MIMO Tri-band Gigabit, 1000+2166+2166 Mbps - Key Features:
- Tri-Band (5 GHz + 5GHz + 2.4 GHz)
- 4×4 AC, MU-MIMO
- 2 USB 3.0 Ports
- Dual-Core CPU
- Beamforming Technology
- 8 Adjustable Antennas
- Smart Wi-Fi
- Network Standards:
- 802.11b
- 802.11a/g
- 802.11n
- 802.11ac
- Wi-Fi Speed:
AC5400 (N1000 + AC2166 + AC2166) - Wi-Fi Bands:
2.4 and 5 GHz(2x) (simultaneous tri-band) - Wi-Fi Range:
Very Large Household - Number of Ethernet Ports:
- 1x Gigabit WAN port
- 8x Gigabit LAN ports
- Other Ports:
- Two(2) USB 3.0 ports
- Power
- Antennas:
8x external adjustable antennas - Processor:
1.4 GHz dual-core - LEDs:
Status Indicator, MU-MIMO Indicators, illuminated Linksys logo, Wi-Fi, Wi-Fi Protected Setup, Power, Internet, LAN 1?8, USB 3.0, USB 2.0
- Wireless Encryption:
64/128-bit WEP, WPA2 Personal, WPA2 Enterprise - Operation Modes:
- Wireless Router
- Access Point (Bridge)
- Storage File System Support:
- FAT
- NTFS
- HSF+
- Easy Setup:
- Browser-based Setup
- Linksys Smart Wi-Fi Setup
- Certified Operating Systems:
Windows 7, Windows 8.1 - Minimum System Requirements:
- Internet Explorer? 8
- Safari? 5 (for Mac?)
- Firefox? 8
- Google Chrome?
- Dimensions (LxWxH):
264.52 x 318.15 x 66.66 mm (10.41 x 12.53 x 2.62 in.) without antennas - Weight:
1727.7 g (60.94 oz) - Security Features:
- WPA/WPA2
- 128 bit AES link encryption
- WEP
- Regulatory Compliance:
FCC class B - Power Supply:
Input: 100-240V ~ 50-60Hz; Output: 12V, 5A
