HP Dubai – Terrabyt.com HPE ProLiant DL380 Gen10 Intel
Processor family
Intel® Xeon® Scalable 8100 series Intel® Xeon® Scalable 6100 series Intel® Xeon® Scalable 5100 series Intel® Xeon® Scalable 4100 series Intel® Xeon® Scalable 3100 series
Number of processors
1 or 2
Processor core available
28 or 26 or 24 or 22 or 20 or 18 or 16 or 14 or 12 or 10 or 6 or 4
Processor cache
8.25 MB L3 11.00 MB L3 13.75 MB L3 16.50 MB L3 19.25 MB L3 22.00 MB L3 24.75 MB L3 27.50 MB L3 30.25 MB L3 33.00 MB L3 35.75 MB L3 38.50 MB L3
Processor speed
3.6 GHz, maximum depending on processor
Form factor
2U
Power supply type
2 Flexible Slot power supplies, maximum depending on model
Expansion slots
8, for detail descriptions reference the QuickSpecs
Maximum memory
3.0 TB with 128 GB DDR46
Memory slots
24 DIMM slots
Memory type
HPE DDR4 SmartMemory
Drive type
8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD 6 SFF rear drive optional or 3 LFF rear drive optional and 2 SFF rear drive optional 20 SFF NVMe optional NVMe support via Express Bay will limit maximum drive capacity
Network controller
HPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional FlexibleLOM, depending on model
Storage controller
1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1 HPE Smart Array E208i-a, depending on model
Minimum dimensions (W x D x H)
44.55 x 73.03 x 8.74 cm
Weight
14.76 kg
Infrastructure management
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (optional)
Warranty
3/3/3 – Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage.
