Aruba 2930M 24G PoE+ 1-slot Switch
Aruba 2930M 24G PoE+ 1-slot Switch
Product Number | JL 381A |
---|---|
Product Description | HPE OfficeConnect 1920 24G 2SFP Switch |
Ports | (24) RJ-45 Auto-negotiating 10/100/1000 ports (2) SFP 100/1000 Mbps ports |
Throughput | upto 38.6 Mbps |
Routing Switching Capacity | 52 Gbps |
Power Supply | 100-240VAC, 50/60Hz |
Product Dimensions (HxWxD) | 17.42 x 9.69 x 1.73 in |
Product Code | J9779A |
---|---|
Type | Aruba 2530-24-PoE+ Switch |
Ports |
|
Throughput | Up to 9.5 Mp/s (64-byte packets) |
Switching capacity | 12.8 Gb/s |
Dimensions (W x D x H) | 44.2 x 32.26 x 4.45 cm (17.4 x 12.7 x 1.75 in) (1U height) |
Weight | 3.81 kg (8.4 lb) |
PoE power | 195W |
Product Number | JL 385A |
---|---|
Product Description | HPE OfficeConnect 1920 24G 2SFP PoE+370W Switch |
Ports | (24) RJ-45 Auto-negotiating 10/100/1000 PoE+ ports (12) RJ-45 Auto-negotiating 10/100/1000? ports (2) SFP 100/1000 Mbps ports |
Throughput | upto 77.3 Mbps |
Routing/Switching Capacity | 52 Gbps |
PoE Capability | 370W PoE+ |
Product Dimensions (HxWxD) | 17.42 x 12.7 x 1.73 in |
Product Code | JL261A |
---|---|
Type | Aruba 2930F 24G PoE+ 4SFP Switch |
I/O ports and slots |
|
Additional ports and slots | 1 dual-personality (RJ-45 or USB micro-B) serial console port |
Throughput | up to 41.7 Mp/s |
Switching capacity | 56 Gb/s |
PoE Available Power | 370 W |
Dimensions | 4.39 x 44.25 x 30.42 cm ( 1.73 x 17.42 x 11.98 in) 1U height |
Weight | 3.9 kg ( 8.6 lb) |
Type | Aruba 2530-24G-PoE+ Switch |
---|---|
Ports |
|
Memory and processor | Processor: ARM9E @ 800 MHz, 128 MB flash, 256 MB DDR3 DIMM; packet buffer size: 1.5 MB dynamically allocated. |
Throughput | up to 41.6 million pps (64-byte packets) |
Switching capacity | 56 Gb/s |
PoE Power | 195 W |
Latency | 1000 Mb Latency:< 2.3 ?s (LIFO 64-byte packets) 10 Gbps Latency: < 7.4 ?s (LIFO 64-byte packets) |
Product Code | JL256A |
---|---|
Type | Aruba 2930F 48G PoE+ 4SFP+ Switch |
I/O ports and slots | ?48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+) Duplex: 10BASE-T/100BASETX: half or full?1000BASE-T: full only 4 SFP+ 1/10GbE ports; PHY-less |
Additional ports and slots | 1 dual-personality (RJ-45 or USB micro-B) serial console port |
Throughput | up to 112.0 Mp/s |
Switching capacity | 176 Gb/s |
Dimensions | 4.39 x 44.25 x 30.42 cm ( 1.73 x 17.42 x 11.98 in) 1U height |
Weight | 4.46 kg ( 9.83 lb) |
PoE Available Power | 370 W |
Product Code | JL255A |
---|---|
Type | Aruba 2930F 24G PoE+ 4SFP+ Switch |
I/O ports and slots |
|
Additional ports and slots | 1 dual-personality (RJ-45 or USB micro-B) serial console port |
Throughput | up to 95.2 Mp/s |
Switching capacity | 128 Gb/s |
Dimensions | 4.39 x 44.25 x 30.42 cm ( 1.73 x 17.42 x 11.98 in) 1U height |
Weight | 3.9 kg ( 8.6 lb) |
PoE Available Power | 370 W |
