HID HID Access IS OCR316-E
| Multifunctional Reader Specifications | |
|---|---|
| OCR (Optical Character Recognition) | |
| Supported Documents | – ICAO-compliant travel documents (near IR per ICAO 9303 Parts 1-4, 2- and 3-line MRZ) – Near ICAO-compliant documents (e.g. French ID) – ISO-18013 driving licences (1-line MRZ) |
| Magnetic Swipe Reader | |
| Standards | Three-track magnetic cards complying with ISO 7811/2-5 |
| Electronic | |
| Power Supply | +5VDC, <250mA via USB connection |
| Communication Interface | USB 2.0 Full-Speed |
| Communication Protocols | USB HID, CDC (virtual serial), Keyboard Wedge |
| OS Support | Windows 7 & above, Android, Linux |
| Physical | |
| Dimensions | 6 x 2 x 2 in (150 x 44 x 45 mm) |
| Body Material | Dark Grey ABS |
| Illumination | Near IR B900, 870 nm + 2.5% |
| Beeper | Single beep for good read, 3 beeps for bad read |
| Indicators | LEDs for power, good read, and bad read |
| Cable Length | 70 in (1.8 m) |
| VESA Monitor Brackets | |
| HID can supply standard VESA mounting brackets. Contact to confirm monitor compatibility. MOQ applies to custom bracket designs. |
|
| Thermal (Air) | |
| Operating Temperature | 32F to 122F (0C to 50C) |
| Storage Temperature | -4F to 140F (-20C to 60C) |
| Approvals | |
| Safety | EN 62368-1 |
| EMC | FCC 47CFR Part 15 Class A EN 55032 Class B EN 55035 |
