DrayTek VigorSwitch G1085 8-Port Web Smart Gigabit Switch

The?Draytek VigorSwitch G1085?is a compact Web Smart Gigabit managed switch. It offers 8x Gigabit Ethernet ports and enterprise-level features to help businesses to improve network security and stability.

Draytek VigorSwitch G1085 Key?Features

8x GbE Gigabit Ethernet, RJ-45
16 Gbps Switching Capacity
11.9 Mpps Forwarding Rate
Up to 9KB Jumbo Frame
Auto Surveillance & Voice VLAN
QoS (Quality of Service)
ONVIF-Friendly
IP Conflict Prevention
Multiple Admin Accounts
Central Switch Management
Energy-Efficient Ethernet

GET QUOTE

Draytek VigorSwitch G1085 – Technical Specification

Interface

LAN Port:?8x 10/100/1000Base-T Ethernet, RJ-45
Button:?1 x Factory Reset

Capacity

Buffer Size:?4.1 Mbit
Switching Capacity:?16 Gbps
Forwarding Rate:?11.9 Mpps (64 bytes)
MAC Address Table:?8k
Jumbo Frame:?Up to 9KB

Networking Standards

IP Version: IPv4, IPv6
Ethernet Standards:
– 802.3 10Base-T
– 802.3u 100Base-T
– 802.3ab 1000Base-T
– 802.3x Flow Control
– 802.3 Auto-Negotiation
– 802.1q Tag-based VLAN
– 802.1p Class of Service
– 802.1d STP
– 802.1w RSTP
– 802.3ad LACP
– 802.1x Port Access Control
– 802.1AB LLDP
– 802.3az EEE

VLAN

Max.Number of VLAN: 256
VLAN Type:
– 802.1q Tag-based
– MAC-based
– Management VLAN
– Voice VLAN
– Surveillance VLAN
Port Isolation: Yes

ONVIF Surveillance

Discovery: Yes
Surveillance Topology: Yes
Real-Time Video Streaming: Yes
ONVIF Device Maintenance:?Device Info, Reset Factory Default, Time Settings, Reboot

QoS

Number of QoS Queues: 8
Queue Scheduling: SPQ, WRR
CoS (Class of Service): 802.1p CoS, DSCP, CoS-DSCP, IP Precedence
Rate Limit/Shaping: Yes

Security

Access Control List:?MAC, IPv4, IPv6
Storm Control:?Broadcast, Unknown Multicast, Unknown Unicast
DoS Defense: Yes
IP Source Guard: Yes
IP Conflict Detection: Yes
IP Conflict Prevention: Yes
Loop Protection: Yes

Link Aggregation

Max. Number of Group:?8
Max. Number of Member in Each Group:?8
Type:?Static, LACP
Traffic Load Balancing:?MAC Address, IP/MAC Address

Multicast

IGMP Snooping:?v2, v3 (BISS)
IGMP Querier:?v2, v3 (BISS)

Management

Web Interface:?HTTP, HTTPS
Command Line Interface:?Telnet, SSH
OpenVPN Client:?Certificate-based authentication
SNMP:?v1, v2, v3
Mail Alert:?Port Status, Port Speed, System Restart, IP Conflict
LLDP: Yes
Syslog: Yes
2-Level Admin Privilege: Yes
Multiple Admin Accounts: Yes
Managed by VigorRouter SWM: Yes
Managed by VigorConnect: Yes
Managed by VigorACS 2: Yes
Config File Export/Import: Yes
SNTP (Simple Network Time Protocol): Yes
Diagnostics Tools:?Port Mirroring, Ping, Cable Test

Physical

19-inch Rack Mountable: Yes,?Mouting Kit Included
Max. Power Consumption:?9 watts
Dimension:?330mm x 230mm x 44mm
Weight:?1.83 kg (4.03 lb)
Operating Temperature:?0 to 45?C
Storage Temperature:?-20 to 70?C
Operating Humidity:?10 to 90% non-condensing
Storage Humidity:?5 to 90% non-condensing
Certificate:?CE FCC
