Dell Dell PowerEdge R940
Technical Specifications
PowerEdge R940 Server
Components
1 Qty 329-BDKB PowerEdge R940 Motherboard
1 Qty 338-BLVR 2x Intel Xeon Gold 6126 2.6G, 12C/24T, 10.4GT/s , 19.25M Cache, Turbo, HT (125W)
DDR4-2666
1 Qty 379-BCQQ 4 CPU Heatsink, 3UPI
1 Qty 379-BCSG iDRAC,Legacy Password
1 Qty 379-BCQY iDRAC Group Manager, Disabled
1 Qty 321-BCMP 2.5″ Chassis with up to 8 Hard Drives
1 Qty 343-BBFE PowerEdge R940 Shipping Material
1 Qty 350-BBJJ Dell/EMC LCD Bezel for PowerEdge R940
1 Qty 350-BBJQ Dell EMC Luggage Tag
1 Qty 350-BBJG No Quick Sync
1 Qty 370-AAIP Performance Optimized
1 Qty 370-ADNU 2666MT/s RDIMMs
4 Qty 370-ADNF 32GB RDIMM 2666MT/s Dual Rank
1 Qty 374-BBQN 2x Intel Xeon Gold 6126 2.6G, 12C/24T, 10.4GT/s , 19.25M Cache, Turbo, HT (125W)
DDR4-2666
1 Qty 385-BBKS iDRAC9, Express
8 Qty 400-ASHP 2TB 7.2K RPM NLSAS 12Gbps 512n 2.5in Hot-plug Hard Drive
1 Qty 405-AANR PERC H740P RAID Controller, 8GB NV Cache, Adapter, Full Height
1 Qty 450-ADWL Single, Hot-plug Power Supply (1+0), 1100W
1 Qty 450-AADY C13 to C14, PDU Style, 10 AMP, 6.5 Feet (2m), Power Cord
1 Qty 461-AAEM Trusted Platform Module 2.0
1 Qty 540-BBUK Broadcom 57416 2 Port 10Gb Base-T + 5720 2 Port 1Gb Base-T, rNDC
1 Qty 750-AABF Power Saving Dell Active Power Controller
1 Qty 770-BCGC ReadyRails Sliding Rails
1 Qty 770-BCGD Cable Management Arm
1 Qty 780-BCDS Unconfigured RAID
1 Qty 991-10021 Qty Consolidation Fee ESG
Software
1 Qty 619-ABVR No Operating System
1 Qty 631-AACK No Systems Documentation, No OpenManage DVD Kit
Service
1 Qty 888-10018 Asset Service – System Shipbox Label (Model, Svc Tag, Order Information, Basic
Config Details)
1 Qty 709-13131 Qty Base Warranty
1 Qty 709-15127 1Yr Parts Only Warranty (Emerging Only)
1 Qty 865-38518 3Yr Basic Warranty – Next Business Day (Emerging Only)
