Description
Connector Type
LC/SC/ST/FC/LSH/MU/MTRJ
Polish Type
UPC/APC
Fiber Mode
OS2 9/125?m
Wavelength
1310/1550nm
Insertion Loss (dB)
?0.3
Return Loss (dB)
UPC?50, APC?60 (LC/SC/ST/FC/MU/MTRJ)
UPC?55, APC?75 (LSH)
Fiber Grade
G.657.A1 (Compatible with G.652.D)
Minimum Bend Radius
10mm
Attenuation at 1310 nm
0.36 dB/km
Attenuation at 1550 nm
0.22 dB/km
Cable Jacket
PVC/LSZH/OFNP
Cable Diameter
2.0/3.0mm
