Description
Connector A
US Conec MTP
Connector B
LC/SC/FC/ST
Fiber Mode
OM4 50/125?m
Wavelength
850/1300nm
40/100G Ethernet Distance
150m at 850nm
10G Ethernet Distance
400m at 850nm
Glass Fiber
Corning ClearCurve?
Minimum Bend Radius
7.5mm
Trunk Diameter
3.0mm-11.7mm
Breakout Leg
2.0mm (Duplex), 2.0/0.9mm (Simplex)
MTP Connector IL
?0.35dB
Standard Connectors IL
?0.2dB
MTP Connector RL
?20dB
Standard Connectors RL
?30dB
