Description
Connector A
US Conec MTP
Connector B
US Conec MTP
Fiber Mode
OM4 50/125?m
Wavelength
850/1300nm
400G Ethernet Distance
100m at 850nm
Glass Fiber
Corning ClearCurve?
Polish Type
APC to APC
Minimum Bend Radius
7.5mm
Insertion Loss
0.35dB Max (0.15dB Typ.)
Return Loss
?20dB
Cable Diameter
3.0mm (16 Fibers)/ 3.5mm (32 Fibers)
Cable Jacket
Plenum (OFNP)
