Commax Commax DRC-900LC/RF1
| Feature | Specification |
|---|---|
| Power source | DC 12V, 1A |
| Power consumption | Standby: 200mA, Maximum: 500mA |
| Mount type | Surface-mounted type |
| Operating temp. | -30C-+60C |
| Wiring | UTP (Cat. 5e) |
| Distance | Max. 300m VD-103(N) |
| RFID card | 13.56MHz (Optional) |
| Image sensor | C-MOS (Pin-hole type) |
| Angle of view | Horizontal: 47, Vertical: 35 |
| Min. Illumination | 3 Lux (Up to 300mm from camera to an object) |
| Lighting | Color: white LED x 2 |
| Dimension (mm) | 136 (W) x 260 (H) x 36 (D) |
| Rain-shield (mm) | 140 (W) x 260 (H) x 65 (D) |
