| General | |
| Device type | Switch – 24 ports – unmanaged& |
| Enclosure type | Desktop, rack-mountable |
| Ports | 22 x 10/100/1000 + 2 x combo SFP |
| Power over Ethernet (PoE) | N/A |
| Performance | Switching capacity: 48 Gbps Forwarding performance (64-byte packet size) : 35.7 Mpps |
| MAC address table size | 8000 entries |
| Jumbo frame support | Yes |
| Features | Flow control, Layer 2 switching, auto-negotiation, auto-uplink (auto MDI/MDI-X), Weighted Round Robin (WRR) queuing, quality of service (QoS), cable diagnostics, loop detection, Energy Efficient Ethernet |
| Compliant standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3az, IEEE 802.1p, IEEE 802.3x |
| Status indicators | Power, link/activity, cable diagnostics, loop detection |
| Expansion and Connectivity | |
| Interfaces | 24 x 10Base-T/100Base-TX/1000Base-T – RJ-45 2 x SFP (mini-GBIC) |
| Power | |
| Power device | Power supply – internal |
| Voltage required | 100-240V AC/50-60 Hz universal input |
| Electric current required | N/A |
| Miscellaneous | |
| Width | 11 in |
| Depth | 6.7 in |
| Height | 1.8 in |
| Weight | 3.59 lbs |
| Fanless | Yes |
| Compliant standards | UL 60950, FCC CFR47 Part 15, CSA 22.2 |
| Localization | Chinese (simplified), German, French, Italian, Spanish, Japanese |
| Software/System Requirements | |
| OS required | N/A |
| Manufacturer Warranty | |
| Service and support | Limited lifetime warranty |
| Service and support details | Limited warranty – replacement – lifetime Limited warranty – power supply and fans – 1 year Technical support – phone consulting – 1 year |
| Environmental Parameters | |
| Min operating temperature | 32 F |
| Max operating temperature | 104 F |
| Humidity range operating | 10 – 90% (non-condensing) |
| Min storage temperature | -4 F |
| Max storage temperature | 158 F |
| Humidity range storage | 10 – 90% (non-condensing) |
