Cisco C9410R Catalyst Switch 9400 Series Specification |
|
|
Total number of slots |
10 |
|
Line-card slots |
8 |
|
Supervisor engine slots |
2 |
|
Dedicated supervisor engine slot numbers |
5 and 6 |
|
Supervisor engine redundancy |
Yes |
|
Supervisor engines supported |
C9400-SUP-1, C9400-SUP-1XL, C9400-SUP-1XL-Y |
|
Maximum PoE per slot |
2880W |
|
Maximum Bandwidth scalability per line-card slot |
Up to 480 Gbps on all slots |
|
Number of power supply bays |
8 |
|
AC input power |
Yes |
|
Integrated PoE |
Yes |
|
Power supplies supported |
3200W AC, 2100W AC |
|
Number of fan-tray bays |
1 |
|
Location of 19-inch rack-mount |
Front |
|
Dimensions (H x W x D) |
22.61 x 17.30 x 16.30 in. (57.43 x 43.97 x 31.70cm) |
|
Rack Units (RU) |
13 RU |
|
Chassis weight (with fan tray) |
65.0 lb (29.48 kg) |
|
Mounting |
19-in. rack compatible (19-in. rack and cable guide hardware included) |
|
Regulatory compliance |
22.61 x 17.30 x 16.30 in. (57.43 x 43.97 x 31.70cm) |
|
Safety |
UL 60950-1
CAN/CSA-C222.2 No. 60950-1 EN 60950-1 IEC 60950-1 AS/NZS 60950.1 IEEE 802.3 |
|
EMC |
47 CFR Part 15
CISPR22 Class A KN 32 Class A EN 300 386 V1.6.1 EN 55022 Class A EN 55032 Class A CISPR 32 Class A EN61000-3-2 EN61000-3-3 ICES-003 Class A TCVN 7189 Class A V-3 Class A CNS13438 Class A CISPR24 EN 300 386 EN55024 TCVN 7317 KN35 |
|
Industry EMC, safety, and environmental standards |
NEBS: Operating temperature: -5 to 55C
Relative Humidity: 10-93% Operating Altitude: up to 1829 m (6000 ft) at 55C ETSI 300-019 Requirements are covered under GR-63-CORE with some deviations. SR-3580 NEBS level 3 (GR-63-CORE, to current issue, GR-1089-CORE, to current issue) ETS 300 019-2-1, Class 1.2 Storage ETS 300 019-2-2, Class 2.3 Transportation ETS 300 019-2-3, Class 3.2 Stationary EN50121-4 EN 300 386 |
|
ROHS compliance |
ROHS5 |
Cisco C9410R Catalyst Switch 9400 Series
Designed for enterprise-class networks, the Cisco C9410R Catalyst Switch 9400 Series is a high-performance, modular switch that provides unmatched security, scalability, and flexibility. It features 10 slots in total, including 2 supervisor engine slots (5 and 6) and 8 line-card slots. Each slot can handle up to 480 Gbps of traffic, guaranteeing smooth network operation. With compatibility for several supervisor engines, including C9400-SUP-1, C9400-SUP-1XL, and C9400-SUP-1XL-Y, the switch offers redundancy. The Cisco C9410R is perfect for large-scale deployments since it has eight power supply bays, integrated PoE that can offer up to 2880W per slot, and strong regulatory compliance. Supported by Cisco’s dependable network technology, it is ideal for contemporary data center settings in Dubai and the United Arab Emirates and is designed to work with 19-inch racks.
