Buy Cisco C9300L-24UXG-4X-E Network Switch In Dubai, UAE

Cisco C9300L-24UXG-4X-E Catalyst Switch

The Cisco Catalyst 9300 Series switches are Cisco’s leading stackable enterprise switching platform built for security, IoT, mobility, and cloud. They are the next generation of the industry’s most widely deployed switching platform.

C9300L-24UXG-4X-E Specification
Product Description		Catalyst 9300 24-port fixed uplinks UPoE, 8xmGig, 4X10G uplinks, Network Essentials
FRU Power Supply		Yes
FRU Fans		Yes
Modular Uplinks		No
Stacking Bandwidth Support		320 Gbps
Cisco StackPower		No
Catalyst 9800 Embedded WLC		Yes (50 APs)
SD-Access Support		Yes (256 Virtual Networks)
Total 10/100/1000,Multigigabit copper or SFP Fiber		24 UPoE 8xmGig
Uplink Configuration		4x 10G fixed uplinks
Default AC power supply		1100W AC
Available PoE power		880W
Total number of MAC addresses		32,000
Total number of IPv4 routes (ARP plus learned routes)		32,000 (24,000 direct routes and 8000 indirect routes)
IPv6 routing entries		16,000
Multicast routing scale		8,000
QoS scale entries		5,120
ACL scale entries		5,120
Packet buffer per SKU		16 MB buffer for 24 and 48 port Gigabit Ethernet models
FNF entries		64,000 flow on 24- and 48-port Gigabit Ethernet models
DRAM		8 GB
Flash		16 GB
VLAN IDs		4094
Total Switched Virtual Interfaces (SVIs)		1000
Jumbo frames		9198 bytes
Total routed ports per Catalyst 9300 Series stack		416
Switching capacity		272 Gbps
Switching capacity with stacking		592 Gbps
Forwarding rate		202.38 Mpps
Forwarding rate with stacking		440.47 Mpps
Dimensions (H x W x D) Cms	Chassis only	4.4 x 44.5 x 40.9
	W/ Default Power Supply	4.4 x 44.5 x 48.8
	W/ 1100W Power Supply	4.4 x 44.5 x 48.8
Mean Time Between Failures?MTBF (hours)		332,640
Acoustic noise Measured per ISO 7779 and declared per ISO 9296 Bystander positions operating to an ambient temperature of 25?C ?		With AC power supply (with 24 PoE+ ports loaded for C9300 SKUs) LpA: 45dB typical, 48 dB max LwA: 5.6B typical, 5.9B max With AC power supply (with half the number of PoE+ ports loaded for C9300L SKUs) LpA: 44dB typical, 47 dB max LwA: 5.5B typical, 5.8B max Typical: Noise emission for a typical configuration Maximum: Statistical maximum to account for variation in p
Connectors and cabling		1000BASE-T ports: RJ-45 connectors, 4-pair Cat 5E UTP cabling Multigigabit-T ports: RJ-45 connectors, 4-pair Cat 5E, Cat 6, Cat 6A UTP cabling 1000BASE-T SFP-based ports: RJ-45 connectors, 4-pair Cat 5E UTP cabling SFP transceivers: LC fiber connectors (single-mode or multimode fiber) SFP+ transceivers: LC fiber connectors (single-mode or multimode fiber) QSFP+ transceivers: MPO and LC fiber connectors (single-mode or multimode fiber) QSFP+ connector SFP+ connector Cisco StackWise stacking ports: copper-based Cisco StackWise cabling Cisco StackPower: Cisco proprietary power stacking cables Ethernet management port: RJ-45 connectors, 4-pair Cat 5 UTP cabling Management console port: RJ-45-to-DB9 cable for PC connections
Power connectors		Customers can provide power to a switch by using the internal power at the back of the switch Internal power supply connector: The internal power supply is an auto-ranging unit. It supports input voltages between 100 (115 for 1100WAC) and 240 VAC. Use the supplied AC power cord to connect the AC power connector to an AC power outlet
Safety certifications		UL 60950-1 CAN/CSA-C222.2 No. 60950-1 EN 60950-1 IEC 60950-1 AS/NZS 60950.1 IEEE 802.3
Electromagnetic emissions certifications ?		47 CFR Part 15 CISPR22 Class A EN 300 386 V1.6.1 EN 55022 Class A EN 55032 Class A CISPR 32 Class A EN61000-3-2 EN61000-3-3 ICES-003 Class A TCVN 7189 Class A V-3 Class A CISPR24 EN 300 386 EN55024 TCVN 7317 V-2/2015.04 V-3/2015.04 CNS13438 KN32 KN35 IEC 61000-6-1 EN 61000-6-1 Additional Certifications for C9300L SKUs: QCVN 118:2018/BTTTT CISPR24/25 CISPR 32 Class A VCCI-CISPR 32 Class A EN55035
Environmental		Reduction of Hazardous Substances (ROHS) 5
