Cat6 Bulk Ethernet Network Cable UTP, Solid, PVC CMR, 23AWG
The next step up from standard Cat5e cable, Cat6 is a “4 twisted pairs” network cable used for 1000Base-T Ethernet applications up to 550MHz, can also provide at speed of 10G rate with 30-40m transmission distance. This cable is perfect to all your advanced networking installations.
Description
Cable Type
Category 6
Shielding Type
UTP
Cable Jacket
PVC CMR
Cable Length
1000ft (305m)
Reference Bandwidth
550MHz
Data Rate Support
10/100/1000Base-T
Wire Gauge
23AWG
Conductor Type
Pure Bare Copper Wire
Conductor Diameter (mm)
0.565 ? 0.005
Cable Outer Diameter (mm)
6.20 ? 0.40
Maximum Installation Tension (N)
110
Bend Radius (mm)
26.4
Standard
ISO/IEC 11801, ANSI/TIA-568.2-D
Operating Temperature
-20 to +75?C (-4 to 167?F)
Installation Temperature
-10 to +50?C (-14 to 122?F)
Product Spotlights
High Performance
1 Gigabit at 23AWG tested up to 550MHz bandwidth
>99.95% copper content, less return loss & better transmission performance than CCA
Spine for added strength to help ensure a clean signal
Wide opening design reduces tension, easy to pull out
Wide Application
1,000 ft. for creating custom-length Cat6 patch cables
Low-smoke PVC jacket accommodates in-wall and under raised floor use
Ideal for indoor voice, data, video and security networking applications
Protocols and Safety Standards
Support PoE, PoE+ and PoE++ (IEEE 802.3af/at/bt)
Comply with ISO/IEC 11801, ANSI/TIA-568.2-D
Tested with a Fluke DSX-8000 Versiv CableAnalyzer
CE, Reach, RoHS Certified and UL Listed
