Key Specifications
Power supply | Wide-range, external, included in the box |
Input voltage | 100 to 240?VAC1.2?A50/60?Hz Class?I |
Output | 19?VDC3.16?A |
Efficiency | Energy Star EPS2.0/ ErP Lot 7Energy Efficiency DOE Level VI |
Input | 19?VDC3.16?A |
Video outputs | 2 simultaneously |
connector | 1x HDMI 2.0a 1x DisplayPort 1.2 (via USB-C) |
Standards | H.265 / HEVC (ISO/IEC 23008-2) H.264 (ISO/IEC 14496-10) MPEG?4 |
MP | up to 32?Mbps |
4K?UHD | up to 32?Mbps |
HD | up to 20?Mbps |
SD | up to 6?Mbps per stream |
GOP structure | I, IP, IBBP |
Monitor resolutions | 1920?x?1280 (HD) at 60?Hz 3840?x?2160 (UHD) at 30?Hz |
Frequency range | 300?Hz to 3.4?kHz |
Data rate | 80?kbps at 8?kHz sampling rate |
Frequency range | 300?Hz to 6.4?kHz |
Data rate | 640?kbps at 16?kHz sampling rate |
Data rate | 48?kbps at 16?kHz sampling rate 80?kbps at 16?kHz sampling rate |
Signal-to-noise ratio | >?50?dB |
