Key Specifications
| Imager | 1/2.8 in. CMOS sensor |
| Effective Picture Elements (Pixels) | 1944 x 1212 (2.35 MP) |
| Lens | 30x motorized Zoom4.3 mm to 129 mmF1.6 to F4.7 |
| Field of View (FOV) | 2.3? to 64.7? |
| Focus | Automatic with manual override |
| Iris | Automatic with manual override |
| Digital Zoom | 12x |
| Day/Night switch | Automatic IR cut filter |
| Color | 0.0077?lx |
| Monochrome | 0.0008?lx |
| High dynamic range | 120 dB WDR |
| Measured according to IEC 62676 Part 5 | 100 dB WDR |
| Common Product Platform | CPP13 |
| DORI | Distance to object |
| WIDE 1X | TELE 30X, Scene width |
| Detection 25 px/m(8 px/ft) | 61 m(200 ft), 1913 m(6276 ft), 77 m(252 t) |
| Observation 63 px/m(19 px/ft) | 24 m(79 ft), 765 m(2510 ft), 31 m(100 ft) |
| Recognition 125 px/m(38 px/ft) | 12 m(39 ft), 383 m(1255 ft), 15 m(50 ft) |
| Identification 250 px/m(76 px/ft) | 6 m(20 ft), 191 m(628 ft), 8 m(25 ft) |
| Modes for viewing the video area of pre-position settings | Automatic exposure, either full-screen or defined to a specific area Focus |
