Key Specifications
| Imager | 1/2.8? progressive scan CMOS |
| Effective Picture Elements | 1945 x 1097 (2.13 MP) |
| Lens | 30x zoom4.5 mm – 135 mm (F1.6 – F4.4) |
| Optical Zoom Field of View (FOV) | 2.4? – 60.9? |
| Focus | Automatic with manual override |
| Iris | Automatic with manual override |
| Digital Zoom | 16x |
| Color | 0.0186 lux |
| Mono | 0.004 lux |
| High dynamic range | 120 dB WDR |
| Measured according to IEC 62676 Part 5 | 107?dB WDR |
| Number of LEDs | 4 |
| Wavelength | 850 nm |
| Distance | 180 m (590 ft) (Detection) |
| Beam angle | Wide beam: 36?Narrow beam: 6.3? |
| Analysis type | Essential?Video?Analytics |
| Configurations | Silent VCA / Profile1 – 16 |
| Alarm rules (combinable) | Any object Object in field Crossing line Entering field Leaving field Loitering Following route Idle object Removed object Counter Occupancy Crowd detection Condition change Similarity search Tampering |
| Object filters | Duration Size Aspect ratio v/h Speed Direction Color Object classes (Upright persons, Bikes, Cars, Trucks) |
| Calibration | Automatic self-calibrating when height is set |
