Key Specifications
| Imager | 1 in. Exmor R CMOS Sensor |
| Effective Picture Elements (Pixels) | 5544 x 3694 (20.47?MP) |
| Lens | 12x motorized Zoom; 9.3 mm to 111.6 mm; F2.8 to F4.5 |
| Field of view (FOV) (with optic image stabilizer ON) | 6.1? to 64.6? (6.1? to 64.5?) |
| Focus | Automatic with manual override, Region per pre-position |
| Iris | Automatic with manual override |
| Digital zoom | 12xNote: Super resolution zoom is always on when digital zoom is <1.5X. This feature is not available at higher zoom values. |
| Color | 0.292 lx |
| Monochrome | 0.0110 lx |
| High dynamic range (measured according to IEC 62676 Part 5) | 62 dB |
| Common Product Platform | CPP13 |
| DORI | Distance, To, Object |
| WIDE 1X | TELE 12X, Scene width |
| Detection25 pixels/m(8 pixels/ft) | 121?m(397 ft), 1441?m(4728 ft), 154?m(505 ft) |
| Observation63 pixels/m(19 pixels/ft) | 48?m(157 ft), 572?m(1877 ft), 61?m(200 ft) |
| Recognition125 pixels/m(38 pixels/ft) | 24?m(79 ft), 288?m(945 ft), 31?m(102 ft) |
| Identification250 pixels/m(76 pixels/ft) | 12?m(39 ft), 144?m(472 ft), 15?m(49 ft) |
| Modes for viewing the video area of pre-position settings | Automatic exposure, either full-screen or defined to a specific area Focus |
| Gain control | AGC, Fixed, Region per pre-position |
| Aperture Correction | Horizontal and vertical |
