Key Specifications
| Imager | 1 in. Exmor R CMOS Sensor |
| Effective Picture Elements (Pixels) | 5544 x 3694 (20.47?MP) |
| Lens | 12x motorized Zoom; 9.3?mm to 111.6?mm; F2.8 to F4.5 |
| Field of View (FOV)(with optic image stabilizer ON) | 6.1? to 64.6? (6.1? to 64.5?) |
| Focus | Automatic with manual override |
| Iris | Automatic with manual override |
| Digital zoom | 12X Note: Super resolution zoom is always on when digital zoom is <1.5X. This feature is not available at higher zoom values. |
| Color | 0.292 lx |
| Monochrome | 0.0110 lx |
| Gain control | AGC, Fixed |
| Aperture Correction | Horizontal and vertical |
| Electronic Shutter Speed (AES) | 1/1 sec to 1/10000 sec (22 steps) |
| Signal-to-Noise Ratio (SNR) | >55?dB |
| Day/Night switch | Automatic IR cut filter |
| Backlight compensation (BLC) | On / Off / Intelligent Auto Exposure (IAE) |
| White balance | 2000?K to 10,000?K ATW, AWB Hold, Extended ATW, Manual, Sodium Lamp Auto, Sodium Lamp |
| Day/Night | Monochrome, Color, Auto |
| Defog mode feature | Improves visibility when viewing foggy or other low-contrast scenes. |
| Noise Reduction | Intelligent Dynamic Noise Reduction |
| High dynamic range (measured according to IEC 62676 Part 5) | 62 dB |
