Technical specifications
Electrical
Maximum power 9 W
Rated power 6 / 3 / 1.5 W
Sound pressure level
at 6 W / 1 W (1 kHz, 1 m)
94 dB / 86 dB (SPL)
Sound pressure level
at 6 W / 1 W (4 kHz, 1 m)
106 dB / 98 dB (SPL)
Effective frequency range
(-10 dB)
80 Hz to 18 kHz
Opening angle
at 1 kHz/4 kHz (-6 dB)
175? / 55?
Rated voltage 100 V
Rated impedance 1667 ohm
Connection Flying leads
Mechanical
Diameter 199 mm (7.8 in)
Maximum depth 70.5 mm (2.8 in)
Mounting cut-out 165 + 5 mm (6.5 + 0.20 in)
Speaker diameter 152.4 mm (6 in)
Weight 620 g (1.37 lb)
Color White (RAL 9010)
Environmental
Operating temperature -25 ?C to +55 ?C (-13 ?F to +131 ?F)
Storage temperature -40 ?C to +70 ?C (-40 ?F to +158 ?F)
Relative humidity <95%
