Key Specifications
Supply voltage Adaptor | 100 to 240?VAC, 50/60?Hz |
Current Consumption voltage Adaptor | 1.9?A (100?VAC) to 1?A 240 (VAC) |
DC voltage Control Unit | 24?V, 6.0?A |
Maximum number of Discussion Devices per Extension Unit | 40 Discussion Devices per trunk/tap-off 85 Discussion Devices in total 24?V, Max 5.2?A (short-circuited protected) |
Dimensions including feet(H x W x D) | 45?x?440?x?200?mm(1.8?x?17.3?x?7.9?in) 19? wide, 1?RU high |
Height of feet | 5.5?mm (0.2?in) |
Mounting | Tabletop or 19? rack |
Weight | Approx. 4.12 kg (9.1 lb) |
Material (top and base) | Painted metal |
Color (top and base) | Traffic black (RAL 9017) matt-gloss |
Rim front panel | Pearl light grey (RAL 9022) matt-gloss |
Operating temperature | 5??C to +45??C (+41??F to +113??F) |
Storage and transport temperature | -40??C to +70??C (-40??F to +158??F) |
Relative humidity | 5% to 98% non-condensing |
