Key Specifications
| Operating Voltage Range | 5 to 16 VDC |
| Current Draw | 60 to 220 mA (peak), 16V (see manual for details) |
| Environmental rating | IP 55 (IP 65 with optional gasket) |
| Operating temperature | – 25 ?C to 65 ?C (-15 ?F to 150 ?F) |
| Humidity | 5 to 95%, no condensation water |
| Housing Material | Polycarbonate (UL 94) |
| Color | Black |
| Display | Mulitcolored RGB LED bar |
| Panel connection | Terminal strip |
| Card compatibility | iCLASS Bosch coded MIFARE classicBosch coded MIFARE DESFire EV1 When using configuration card: MIFARE classic serial numberMIFARE DESFire EV1 serial number (32 bit standard, 56 bit optional) |
| Operating freqeuncy | 13.56 MHz |
| eyeyTypical reading distance 1)LECTUS secure 5000 RO | 14 cm (iCLASS card) 5 cm (MIFARE DESFire EV1 card) 13 cm (MIFARE Classic card) 8 cm (iCLASS key fob) 5 cm (MIFARE Classic key fob) |
| Dimension (W x H x D) | 8.5 x 12.2 x 2.8 cm |
| Weight (g) | 226 g net |
