Name: Belden 8761 Electronic, 2 C #22 Str TC, PE Ins, OS, PVC Jkt, CM
SKU: Belden 8761H
Availability: InStock

Belden 8761 Electronic, 2 C #22 Str TC, PE Ins, OS, PVC Jkt, CM

د.إ 650.00

Electronic, 2 Conductor 22AWG (7×30) Tinned Copper, PE Insulation, Overall Beldfoil? Shield, PVC Outer Jacket, CM

Suitable Applications	low voltage analog signals (4-20ma, 0-10v, …); low voltage digital control (24v, ?); line level audio; computer communication; panel wiring

Element	Number of Element	AWG	Stranding	Material
Pair(s)	1	22	7×30	TC – Tinned Copper

Element	Material	Thickness	Color Code
Pair(s)	PE – Polyethylene	0.017 in (0.43 mm)	Black, Clear

Shield Type	Material	Coverage	Drainwire Type
Tape	Bi-Laminate (Alum+Poly)	100%	22 AWG (7×30) TC

Material	Thickness	Nom. Diameter
PVC – Polyvinyl Chloride	0.025 in (0.64 mm)	0.175 in

Cable Diameter (Nominal)	0.175 in (4.45 mm)

Element	Nom. Conductor DCR	Nom. Capacitance Cond-to-Cond	Nom. Capacitance Cond-to-Other (Conds + Shield)	Nom. Characteristic Impedence	Max. Current
Pair(s)	16 Ohm/1000ft (52 Ohm/km)	24 pF/ft (79 pF/m)	47 pF/ft (150 pF/m)	64 Ohm	2.9 Amps per Conductor at 25?C

UL Voltage Rating
300 V (CM), 300 V (UL AWM 2092))

UL Rating	Operating
60?C (UL AWM 2092)	-20?C to +60?C

Stationary Min.	Installation Min.
1.8 in (46 mm)	1.8 in (46 mm)

Max. Pull Tension	27 lbs (12 kg)
Bulk Cable Weight	16 lbs/1000ft (24 kg/km)

Environmental Suitability	Indoor
Flammability / Fire Resistance	UL1685 UL Loading, IEC 60332-1-2
NEC / UL Compliance	Article 800, CM
AWM Compliance	2092
CEC / C(UL) Compliance	CM
CPR Euroclass	Eca
European Directive Compliance	EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
Plenum Number	88761, 87761, 82761

Update and Revision	Revision Number: 0.371 Revision Date: 07-02-2021
