Technical Specifications
Output
Battery Output Voltage
240 V
Batteries & Runtime
Battery type
Lead-acid battery
Battery mounting
Floor mounted
Expected Battery Life (years)
3 – 5
Battery blocks per string
20
Physical
Maximum Height
368MM, 36.8CM
Maximum Width
190MM, 19.0CM
Maximum Depth
485MM, 48.5CM
Net Weight
60.0KG
Shipping weight
63.0KG
Shipping Height
460MM, 46.0CM
Shipping Width
290MM, 29.0CM
Shipping Depth
570MM, 57.0CM
Color
Black
Environmental
Operating Temperature
0 – 40 ?C
Operating Relative Humidity
0 – 95 (Non-condensing) %
Operating Elevation
0 – 3000meters
Storage Temperature
-15 – 40 ?C
Storage Relative Humidity
0 – 95 (Non-condensing) %
Storage Elevation
0 – 15000meters
Conformance
Approvals
CE, EAC, EN/IEC 62040-1
Standard warranty
2 years repair or replace
Sustainable Offer Status
RoHS
Compliant
