Output
Max Configurable Power (Watts)
8.0kWatts /?8.0kVA
Output Voltage Note
Configurable for 220 : 230 or 240 nominal output voltage
Output Voltage Distortion
Less than 2 %
Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages
220?V, 240?V
Topology
Double conversion online
Input
Input frequency
40 – 70 Hz Auto-sensing
Input voltage range for main operations
160 – 285V
Other Input Voltages
220?V, 240?V
Batteries & Runtime
Battery type
Lead-acid battery
Included Battery Modules
2
Typical recharge time
4hour(s)
Nominal Battery Voltage
+/- 96 V
Expected Battery Life (years)
3 – 5
Battery Charge Power (Watts)
392?Watts
Extendable Run Time
1
Battery Volt-Amp-Hour Capacity
1680
Runtime
Efficiency
Communications & Management
Interface Port(s)
RJ-45 Serial, Smart-Slot, USB
Control panel
LED Status display with on line : on battery, Multifunction LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO)
Yes
Physical
Maximum Height
217MM, 21.7CM
Maximum Width
440MM, 44.0CM
Maximum Depth
620MM, 62.0CM
Net Weight
81.12KG
Shipping weight
83.14KG
Shipping Height
414MM, 41.4CM
Shipping Width
590MM, 59.0CM
Shipping Depth
790MM, 79.0CM
Environmental
Operating Temperature
0 – 40 ?C
Operating Relative Humidity
0 – 95 (Non-condensing) %
Operating Elevation
0 – 2011.68meters
Storage Temperature
-15 – 45 ?C
Storage Relative Humidity
0 – 95 (Non-condensing) %
Storage Elevation
0 – 15240meters
Audible noise at 1 meter from surface of unit
55.0dBA
Online thermal dissipation
1774.0BTU/hr
Protection Class
IP20
Conformance
Approvals
CE, EN/IEC 62040-1
Standard warranty
3 years repair or replace (excluding battery) and 2 years for battery
