| provided equipment | Smart UPS signalling RS-232 cable User manual | |
|---|---|---|
| Number of tare power | 68?W | |
| Number of power module free slots | 0 | |
| Number of power module filled slots | 0 | |
| redundant | No | |
| UPS size | S |
| depth | 62?cm | |
|---|---|---|
| height | 17.78?cm | |
| mounting preference | No preference | |
| net weight | 51.9?kg | |
| mounting mode | Rack-mounted with kit | |
| two post mountable | 0 | |
| USB compatible | No | |
| width | 44?cm |
| network frequency | 40…70 Hz auto-sensing | |
|---|---|---|
| number of input connectors | 1 hard wire 3-wire (1P + N + E) | |
| input voltage limits | 160…285 V | |
| Input voltage | 220 V 240 V | |
| maximum input current | 30?A | |
| switching current capacity | 40?A | |
| input voltage | 230 V |
| rated power in W | 6000?W | |
|---|---|---|
| Maximum configurable power in W | 6000?W | |
| harmonic distortion | Less than 2 % | |
| output frequency | 50/60 Hz +/- 3 Hz sync to mains | |
| Output voltage | 220 V 240 V | |
| crest factor | 3 : 1 | |
| UPS type | Double conversion online | |
| Wave type | Sine wave | |
| output connector type | Hard wire 3-wire (H N + E) 1 | |
| nb of power socket outlets | 2 IEC 60320 C13 1 IEC 60320 C19 | |
| bypass type | Internal bypass (automatic and manual) | |
| curve equation | Efficiency | |
| curve fixed loss | 0.0127 | |
| curve load maximum | 100?% | |
| curve load minimum | 2?% | |
| curve proportional loss | 0.0316 | |
| curve square loss | 0.020 | |
| curve X-axis maximum | 100?% | |
| curve test cond ID | Curve fit to measured efficiency data. All measurements taken in normal operating mode, at typical environmental conditions, with nominal electrical input and balanced resistive load (PF = 1.0) output. | |
| curve X-axis minimum | 0?% | |
| curve X-axis title | Load | |
| curve X-axis units | Percentage | |
| curve Y-axis maximum | 100?% | |
| curve Y-axis minimum | 50?% | |
| curve Y-axis title | Efficiency | |
| curve Y-axis units | Percentage | |
| full load runtime | 00:02:15 6000 W | |
| graph display | 1 | |
| half load runtime | 00:08:30 3000 W | |
| output voltage | 230 V | |
| Maximum configurable power in VA | 6000?VA | |
| rated power in VA | 6000?VA |
| product certifications | CE | |
|---|---|---|
| standards | EN/IEC 62040-1 |
| ambient air temperature for operation | 0?40??C | |
|---|---|---|
| relative humidity | 0?95?% non-condensing | |
| operating altitude | 0…6600 ft | |
| ambient air temperature for storage | -15?45??C | |
| storage Relative Humidity | Non-condensing 0?95?% | |
| storage altitude | 0.00?15240.00?m | |
| acoustic level | 55 dBA | |
| heat dissipation | 1330.74?Btu/h | |
| show note OP temperature | No | |
| IP degree of protection | IP20 |
| battery type | Lead-acid battery | |
|---|---|---|
| number of battery filled slots | 2 | |
| number of battery free slots | 0 | |
| Battery recharge time | 4?h | |
| additional information | Configurable for 220 : 230 or 240 nominal output voltage | |
| liquid value | 0 | |
| battery voltage | +/- 96 V | |
| battery curve | C | |
| battery charger power | 239?W rated | |
| Battery power in VAH | 960 VAh capacity 960 VAh runtime | |
| battery life | 3?5?year(s) | |
| battery option | SRTG192XLBP4 1 2688 VAh SRTG192XLBP4 2 4488 VAh SRTG192XLBP4 3 6461 VAh SRTG192XLBP4 4 8000 VAh | |
| extended runtime | 1 |
| preinstalled device | Network management card | |
|---|---|---|
| control panel | LED Status display with on line : on battery Multifunction LCD status and control console | |
| alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm | |
| Emergency power off | Yes |
| Surge energy rate | 600?J |
|---|
| Package 1 Weight | 59?kg | |
|---|---|---|
| Package 1 Height | 27.5?cm | |
| Package 1 width | 59?cm | |
| Package 1 Length | 79?cm |
| Warranty | 3 years repair or replace (excluding battery) and 2 years for battery |
|---|
