Technical Specifications
Output
Max Configurable Power (Watts)
670?Watts /?1.0kVA
Output Voltage Distortion
Less than 5 %
Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz Sync to mains
Topology
Line interactive
Waveform type
Sine wave
Input
Input frequency
50/60 Hz +/- 3 Hz Auto-sensing
Input voltage range for main operations
75 – 154 Adjustable, 82 – 144V
Number of Power Cords
1
Batteries & Runtime
Battery type
Lead-acid battery
Typical recharge time
2hour(s)
Replacement Battery
RBC34
Expected Battery Life (years)
4 – 6
RBC Quantity
1
Battery Charge Power (Watts)
107?Watts
Runtime
Efficiency
Communications & Management
Interface Port(s)
DB-9 RS-232, SmartSlot, USB
Control panel
LED status display with load and battery bar-graphs and on line : on battery : replace battery : and overload indicators
Audible Alarm
Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO)
Optional
Available SmartSlot? Interface Quantity
1
Surge Protection and Filtering
Surge energy rating
480Joules
Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height
1.73inches (44MM, 4.4CM)
Maximum Width
17.01inches (432MM, 43.2CM)
Maximum Depth
25.98inches (660MM, 66.0CM)
Net Weight
48.1lbs. (21.82KG)
Shipping weight
56.11lbs. (25.45KG)
Shipping Height
7.52inches (191MM, 19.1CM)
Shipping Width
22.01inches (559MM, 55.9CM)
Shipping Depth
30.51inches (775MM, 77.5CM)
Color
Black
Units per Pallet
8.0
Environmental
Operating Temperature
32 – 104 ?F (0 – 40 ?C)
Operating Relative Humidity
0 – 95 %
Operating Elevation
0 – 10000ft (0 – 3048meters)
Storage Temperature
-15 – 45 ?C
Storage Relative Humidity
0 – 95 %
Storage Elevation
0 – 50000ft (0 – 15240meters)
Audible noise at 1 meter from surface of unit
55.0dBA
Online thermal dissipation
130.0BTU/hr
Conformance
Approvals
FCC part 15 class A, UL 1778
Equipment protection policy
Lifetime : $150000
Standard warranty
2 years repair or replace
Sustainable Offer Status
RoHS
Compliant
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
Proposition 65 Warning
Available in Documentation tab
