Technical Specifications
Output
Battery Output Voltage
72 V
Batteries & Runtime
Battery type
Lead-acid battery
Battery mounting
Floor mounted
Expected Battery Life (years)
3 – 5
Battery blocks per string
6
Physical
Maximum Height
336MM, 33.6CM
Maximum Width
190MM, 19.0CM
Maximum Depth
425MM, 42.5CM
Net Weight
38.0KG
Shipping weight
40.2KG
Shipping Height
325MM, 32.5CM
Shipping Width
235MM, 23.5CM
Shipping Depth
565MM, 56.5CM
Color
Black
Environmental
Operating Temperature
0 – 40 ?C
Operating Relative Humidity
0 – 95 (Non-condensing) %
Operating Elevation
0 – 3000meters
Storage Temperature
-15 – 40 ?C
Storage Relative Humidity
0 – 95 (Non-condensing) %
Storage Elevation
0 – 15000meters
Conformance
Approvals
CE, EAC, EN/IEC 62040-1
Standard warranty
2 years repair or replace
Sustainable Offer Status
RoHS
Compliant
