Technical Specifications
Output
Battery Output Voltage
72 V
Batteries & Runtime
Battery type
Lead-acid battery
Battery mounting
Rack mount
Expected Battery Life (years)
3 – 5
Battery blocks per string
6
Physical
Maximum Height
86MM, 8.6CM
Maximum Width
438MM, 43.8CM
Maximum Depth
632MM, 63.2CM
Net Weight
42.5KG
Shipping weight
53.1KG
Shipping Height
240MM, 24.0CM
Shipping Width
600MM, 60.0CM
Shipping Depth
800MM, 80.0CM
Color
Black
Environmental
Operating Temperature
0 – 40 ?C
Operating Relative Humidity
0 – 95 (Non-condensing) %
Operating Elevation
0 – 3000meters
Storage Temperature
-15 – 40 ?C
Storage Relative Humidity
0 – 95 (Non-condensing) %
Storage Elevation
0 – 15000meters
Conformance
Approvals
CE, EAC, EN/IEC 62040-1
Standard warranty
2 years repair or replace
