Simplex SC/APC 9/125 Single Mode Fiber Optic Pigtail, 0.9 mm PVC Outer Jacket
Fiber optic pigtails provide a fast way to make communication devices in the field. They are designed, manufactured and tested according to protocol and performance dictated by the industrial standards, which will meet your most stringent mechanical and performance specifications.
Description
Connector A
SC
Connector B
Unterminated
Fiber Mode
9/125 ?m
Fiber Count
Simplex
Fiber Grade
G.657.A1
Minimum Bend Radius
30 mm
Polish Type
APC
Cable Diameter
0.9 mm
Cable Jacket
PVC
Jacket Color
Yellow
Wavelength
1310 nm/1550 nm
Durability
500 Times
Insertion Loss
?0.3 dB
Interchangeability
?0.2 dB
Return Loss
?60 dB
Vibration
?0.2 dB
Operating Temperature
-40~75?C
Storage Temperature
-45~85?C
